Frame Colors

Ergo Live14" Seat Width16" Seat Width18" Seat Width
Seat Width* Seat Depth14*1616*1618*16
Caster Size* Rear Wheel Size5/6*24Q5/6*24Q5/6*24Q
Seat Width (cm)364146
Seat Depth(cm)414141
Seat Height(cm)45~5145~5145~51
Backrest Height(cm)33~40.5/40.5~4833~40.5/40.5~4833~40.5/40.5~48
Armrest Height(cm)232323
Calf Length(cm)36~4436~4436~44
Backrest Angle(X°)(-5)、0、5(-5)、0、5(-5)、0、5
Max. User Weight (kg)125125125
Weight W/O Accessories (kg)
Total Weight (kg)11.711.912.1
Overall L x W x H (cm)Min. 92*51*83
Max. 92*51*97
Min. 89*56*83
Max. 89*56*97
Min. 89*61*83
Max. 89*61*97
Overall Collapsed L x W x H (cm)Min. 89*32*83
Max. 89*32*97
Min. 89*32*83
Max. 89*32*97
Min. 89*32*83
Max. 89*32*97

Remark : Karma reserves the right to modify information herein without further notice.
